The standard size requirements below can be utilized when the standard features are acceptable parameters for the project. If you ahve special site conditions, many options, or would like a custom drawing for your project, visit the Solutions Center at www.mlleedind.com.my where a customized drawing can be produced for you within a day.
Model | Total Capacity | Car | Entrance | Serving Height | Shaft | Pit Depth | Headroom | ||||
Width | Depth | Height | Width | Height | Width | Depth | |||||
DW50 | 50-100kg | 610 | 760 | 760 | 320§ | 770 | 750 | 1070 | 950 | - | 1520 |
DW200 | 200kg | 610 | 760 | 760 | 420§ | 770 | 750 | 1200 | 1200 | - | 1520 |
